Sample: 100% prepaid before production.
Normal: 30% in advance,70% aganist copy of B/L
Delivery:
Standard : 35-60days depends orders
Busy Time: 60-80days
Nearst Sea Port: Ningbo or Shanghai Port.
Model 型号 | TM120 | TM140 | TM150 | TM160 | TM180 |
Working Width 工作宽度 | 1200 | 1400 | 1500 | 1600 | 1800 |
Tilling Depth 工作深度 | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 |
No.of Blade 刀片数量 | 24 | 28 | 32 | 32 | 36 |
Matched Power 配套马力 | 25-30 | 30-35 | 35-40 | 40-45 | 50-55 |
Blade Shaft Speed(rpm) | 210 | 210 | 210 | 210 | 210 |
N.W/G.W 净/毛重 | 175/210 | 200/235 | 210/250 | 240/290 | 290/350 |
包装尺寸 Packing Size | 1450*730*730 | 1650*730*730 | 1750*730*730 | 1850*730*730 | 2050*730*730 |
Qty/20'GP 20尺集装箱数 | 36 | 30 | 27 | 27 | 24 |
